Teltonika FM6320 Professional Tracker 3G

Tracker per mezzi di trasporto pesante in tecnologia 3G.

Doppio slot SIM per failover e viaggi internazionali

Micro SD card per il salvataggio di record in caso di mancanza di copertura GSM.

Porta seriale ES232/RS485 per l'inserimento di accessori di terze parti come: sensori LLS, navigatore GARMIN, reder RFID...

Allerta in caso di disconnessione antenna GPS, utile per avvertimento furto.

La confezione contiene: - FM6320 tracker; - antenna GNS/3G (3,0 m ) - antenna GSNN (3,0 m) - cavo per alimentazione

GSM/GPRS/3G features:

UMTS/HSPA+, GSM/GPRS/EDGE module UMTS/HSPA+ bands depending on module: 800/850, 900, 1700, 1900, 2100 MHz (GLOBAL module) 900 / 2100 MHz (EMEA / APAC module) GSM/GPRS/EDGE bands depending on module: 850, 900, 1800, 1900 MHz (GLOBAL module) 900, 1800 (EMEA / APAC module) HSPA+ data up to 21.0 Mbps downlink (GLOBAL module) HSPA+ data up to 5.76 Mbps uplink (GLOBAL module) HSPA+ data up to 7.2 Mbps downlink (EMEA / APAC module) HSPA+ data up to 5.76 Mbps uplink (EMEA / APAC module) UMTS uplink / downlink up to 384 Kbps EDGE uplink up to 236.8 Kbps, downlink up to 296 Kbps GPRS and EDGE class 33 SMS (text, data)

• UMTS/HSPA+ bands depending on module:800/850, 900, 1700, 1900, 2100 MHz (GLOBAL module)900 / 2100 MHz (EMEA / APAC module)
• GSM/GPRS/EDGE bands depending on module:850, 900, 1800, 1900 MHz (GLOBAL module)900, 1800 (EMEA / APAC module)
• 850, 900, 1800, 1900 MHz (GLOBAL module)
• HSPA+ data up to 21.0 Mbps downlink (GLOBAL module)
• HSPA+ data up to 5.76 Mbps uplink (GLOBAL module)
• HSPA+ data up to 7.2 Mbps downlink (EMEA / APAC module)
• HSPA+ data up to 5.76 Mbps uplink (EMEA / APAC module)
• EDGE uplink up to 236.8 Kbps, downlink up to 296 Kbps
• GPRS and EDGE class 33
• SMS (text, data)

GNSS:

NMEA, GGA, GGL, GSA, GSV, RMC, VTG protocol compatible 32 channel GNSS receiver -162 dBm tracking Sensitivity

• NMEA, GGA, GGL, GSA, GSV, RMC, VTG protocol compatible
• 32 channel GNSS receiver
• -162 dBm tracking Sensitivity

Integrated KLINE Dual CAN J1939 J1708 CAN RS485 and 2x RS232 support 4 Digital Inputs for object status monitoring 4 Digital Open-collector Outputs (controlling external relays, LED, buzzers, etc.) 3 Analog Inputs 1-wire interface Ni-Mh 550 mAh internal battery MicroSD card 2 status LED Configuration and firmware update (via FOTA and USB cable) External GSM antenna for higher sensitivity External GNSS antenna for higher sensitivity

• Integrated KLINE
• Dual CAN J1939
• J1708 CAN
• RS485 and 2x RS232 support
• 4 Digital Inputs for object status monitoring
• 4 Digital Open-collector Outputs (controlling external relays, LED, buzzers, etc.)
• 1-wire interface
• Ni-Mh 550 mAh internal battery
• MicroSD card
• 2 status LED
• Configuration and firmware update (via FOTA and USB cable)
• External GSM antenna for higher sensitivity
• External GNSS antenna for higher sensitivity

Integrated 3G/GSM module for worldwide usage even in countries where only 3G is available. Controlled switching between 3G and GSM networks. Easy to mount and fasten firmly 2 LED indication Integrated Ni-MH back up battery Real – Time tracking External 3G/GSM antenna to ensure steady data stream while object is in low signal coverage areas External GNSS antenna for high quality tracking at all-time even when object is in complex areas – from closed/urban streets or canyons to dense forests Smart data acquisition based on: Time Distance Angle Speed difference (Value taken from GNSS or Teltonika Vehicle CAN adapters) Ignition or any other I/O event Saving information to Micro SD card, preventing data loss after prolonged time under no 3G/GSM coverage Sending acquired data via 3G or GPRS (TCP/IP and UDP/IP protocols) Virtual Odometer Dual CAN J1939 reading enables DDD data files to be downloaded remotely J1708 CAN reading interface RS485 and 2x RS232 interfaces for advanced Fuel Level tracking or usage of external devices such as Garmin, LLS, RFID reader, etc. Power saving in Sleep or Deep Sleep modes Authorized driving with up to 500 unique iButton ID list Time synchronization by NTP (Network Time Protocol) if GNSS signal is absent SMS sending/receiving via GPRS Time-zone (UTC/GMT) selection Dynamic SMS events Teltonika Vehicle Can Adapter

• Easy to mount and fasten firmly
• 2 LED indication
• Integrated Ni-MH back up battery
• Real – Time tracking
• External 3G/GSM antenna to ensure steady data stream while object is in low signal coverage areas
• Smart data acquisition based on:TimeDistanceAngleSpeed difference (Value taken from GNSS or Teltonika Vehicle CAN adapters)Ignition or any other I/O event
• Speed difference (Value taken from GNSS or Teltonika Vehicle CAN adapters)
• Sending acquired data via 3G or GPRS (TCP/IP and UDP/IP protocols)
• Dual CAN J1939 reading enables DDD data files to be downloaded remotely
• J1708 CAN reading interface
• Power saving in Sleep or Deep Sleep modes
• Authorized driving with up to 500 unique iButton ID list
• Time synchronization by NTP (Network Time Protocol) if GNSS signal is absent
• Dynamic SMS events

Fuel monitoring with LLS sensors Ignition detection Up to 4x 1-wire Temp sensors 1-wire iButtons Door sensors LED indication Buzzer Internal backup battery CAN interface Remote Tachograph DDD file download RS485 and 2x RS232 for peripheral device support GARMIN FMI support Alarm button Relay Engine block Starter block Trip detection Overspeeding detection Auto Geofencing Detect car towing Car theft prevention 5x LLS support RFID (RS232 and 1Wire interface) support Four profiles

• Fuel monitoring with LLS sensors
• Ignition detection
• Up to 4x 1-wire Temp sensors
• 1-wire iButtons
• Door sensors
• LED indication
• Internal backup battery
• CAN interface
• Remote Tachograph DDD file download
• RS485 and 2x RS232 for peripheral device support
• GARMIN FMI support
• Alarm button
• RelayEngine blockStarter block
• Engine block
• Starter block
• Trip detection
• Overspeeding detection
• Auto GeofencingDetect car towingCar theft prevention
• Detect car towing
• Car theft prevention
• 5x LLS support
• RFID (RS232 and 1Wire interface) support
• Four profiles
